Product Details
Material
Stainless Steel
Coating type
Iron Oxide
Grade
308
This Welding Electrode is a rutile type stainless steel electrode used in welding 18 Cr / 8 Ni austenitic stainless steel to mild steel and low alloyed steels and also for surfacing applications on such steels. Weld metal deposit is austenitic-ferrite stainless steels. Welding Electrode is suitable for AC as well as DC.
Recommendation :
- Re-back the electrodes at 250o C for half an hour.
Weld Metal Composition
| Elements | C | Mn | S | Si | P | Ni | Cr |
| Percentage (%) | 0.06 | 0.80 | 0.015 | 0.80 | 0.012 | 9.0 | 18.50 |
Mechanical Properties
| Tensile Strength N/mm2 | 620 |
| % Elongation | 41.0 |
Size and Recommended Current Range
| Size (mm) | 2.50 | 3.20 | 4.00 | 5.00 |
| AC/DC (Amps.) | 60 - 80 | 80 - 100 | 110 - 140 | 140 - 180 |
| Polarity | ||||
