Product Details
Feature
Proper Working
Application
Welding Purpose
Material
Mild Steel
Size
3.15 mm
This basic coated low hydrogen type Welding Electrode is suited for all position , except vertical down. Welding Electrode operates on both AC and DC and makes welded joints that are tough and crack free with carbon content of up to 0.4 %.
|
|
|
|
|
Weld Metal Composition
| Elements | C | Mn | Si | S | P |
| Percentage (%) | 0.08 | 1.20 | 0.45 | 0.016 | 0.018 |
Mechanical Properties
| Yield Strength N/mm2 | 520 |
| Tensile Strength N/mm2 | 560 |
| % Elongation | 29.0 |
| Charpy Impact Energy | 60 J at - 30o C |
Size and Recommended Current Range
| Size (mm) | 2.50 | 3.20 | 4.00 | 5.00 |
| AC/DC (Amps.) | 70 - 100 | 100 - 150 | 140 - 190 | 190 - 250 |
| Polarity | ||||
